16
EN
CABLE BOX SET UP
OFF
PRESS (
2
3
), THEN (OK)
PRESS (MENU) TO END
Turn on the VCR and the TV, and select the AV
mode on the TV.
Setting cable box output
channel & brand
After installation, set the cable box output’s channel and
its brand correctly; otherwise, the Controller cannot
work correctly.
1
Turn on cable box
Select a channel other than channel 9 on your
cable box.
2
Access Main Menu screen on VCR
Press MENU.
3
Access Tuner Set Up screen
Press %fi to move the highlight bar (arrow) to
“TUNER SET UP”, then press OK.
4
Access Cable Box Set screen
Press %fi to move the
highlight bar (arrow) to
“CABLE BOX SET UP”,
then press OK.
5
Select cable box output channel
Your selection depends
on how your cable box
is connected to your
VCR.
If your cable box is
connected to your
VCR’s ANTENNA IN
terminal on the rear panel
Press
@
#
until the channel number
representing the cable box’s output (CH2 –
CH9) appears on the screen.
If your cable box is connected to your VCR’s
AUDIO/VIDEO IN connectors on the front panel
Press
@
#
until “ON F-1 (FRONT)” appears on
the screen.
If your cable box is connected to your VCR’s
AUDIO/VIDEO IN (L-1) or AUDIO/VIDEO IN
(L-2) connectors on the rear panel
Press
@
#
until “ON L-1 (REAR)” or “ON L-2
(REAR)” appears on the screen.
If you do not use a cable box
Press
@
#
until “OFF” appears on the screen.
123
456
7
89
0
VCR TV CABLE/DBS
2
3 4
3 4
6 7
INITIAL SETTINGS (cont.)
TUNER SET UP
BAND CATV
AUTO CHANNEL SET UP
MANUAL CHANNEL SET
GUIDE CHANNEL SET
3
CABLE BOX SET UP
DBS RECEIVER SET UP
PRESS (5∞), THEN (OK)
PRESS (MENU) TO END
7
5
