55
You have to select which terminal — either VIDEO (composite) or S-VIDEO (Y/C
separate signals) to use as the video input terminal on the front panel.
Make sure to select the correct terminal; otherwise, you may fail in recording
(editing) on this VCR.
You have to select which terminal — either VIDEO (composite) or S VIDEO (Y/C
separate signals) to use as the video input terminal (L-1) on the rear panel.
Make sure you select the correct terminal; otherwise, you may fail in recording
(editing) on this VCR.
You have to select which terminal — either VIDEO (composite) or S VIDEO (Y/C
separate signals) to use as the video input terminal (L-2) on the rear panel.
Make sure you select the correct terminal; otherwise, you may fail in recording
(editing) on this VCR.
Ⅵ REAR AUX L-1
VIDEO
S-VIDEO
Ⅵ FRONT AUX F-1
VIDEO
S-VIDEO
Ⅵ REAR AUX L-2
VIDEO
S-VIDEO
Ⅵ TV OUTPUT 1
720to1080
NO CONV.
ALLto480i
Input/Output settings [IN/OUT]
Ⅵ TV OUTPUT 2
WIDE16:9
NORM4:3
* The default setting is bold in the table below.
Select the apppropriate mode depending on the type of TV you have.
WIDE16:9: Select this for a wide TV set with 16:9 screen image size.
NORM4:3: Select this for a TV set with 4:3 screen image size.
NOTES:
●
When “TV OUTPUT 2” is set to “WIDE16:9”, sometimes the screen image may be
stretched vertically.
●
When “TV OUTPUT 2” is set to “NORM4:3”, sometimes subtitles may not be visible or
the ends of the screen image may be cut off. Normally select “WIDE16:9”.
●
In order to let the equipment determine the screen image size, it is recommended that
you connect the VCR and TV using the component video output connectors or S VIDEO
OUT connector.
ATTENTION:
When recording by down-conversion, the screen image will be stretched vertically
regardless of “TV OUTPUT 2” setting.
Select the apppropriate mode when playing back a D-VHS tape containing a
recording of an HD (High Definition) signal:
720to1080: 720p is up-converted to 1080i and output to the TV. 1080i,
480p, and 480i image formats are output to the TV without
being converted. Select this when the 720p image played back
is distorted.
NO CONV.: 1080i, 720p, 480p, and 480i image formats are output to the
TV just as they are.
ALLto480i: All images will be output to the TV in 480i image format.
NOTE:
When you play back the picture of 1080i, 720p, 480p image format, the signal is not
output from the S-VIDEO or VIDEO output connector.
CONTINUED ON NEXT PAGE \
