VCR TV CABLE/DBS
MULTI-BRAND REMOTE CONTROL
This Remote can control some functions of remote
controllable TVs listed below. Without setting, you can
control a JVC TV.
1
Turn on the TV
Turn on the TV using the Power button on the TV
or its Remote.
2
Set remote operation mode
Set the VCR/TV/CABLE/DBS selector to “TV”.
3
Set TV brand code
Follow the example shown below.
1 Press and hold POWER.
2 Press the Number keys to enter your TV’s
brand code by referring to the table below.
3 Press STOP ( 7 ), and release POWER.
● Once you have set the Remote to operate the
TV, you do not have to set it until you replace
the batteries from the Remote.
● JVC and PANASONIC have two codes. If the
TV does not function with one code, try
entering the other.
4
Operate TV
First set the VCR/TV/CABLE/DBS selector to
“TV”, then press one of the following buttons:
POWER, TV/VCR, TV CH +/–,
(TV
Muting), TV VOL +/–, and Number keys.
● For some brands, you must press ENTER after
having pressed the Number keys to enter a
channel number.
● To operate the VCR, set the VCR/TV/CABLE/
DBS selector back to “VCR”.
NOTES:
●
Depending on the type of TV, some or all functions cannot be
operated using this Remote.
●
It’s not possible to operate a TV not equipped with a remote
sensor.
TV BRAND NAME BRAND CODE
JVC 01, 03
HITACHI 10
MAGNAVOX 02
MITSUBISHI 03
PANASONIC 04, 11
RCA 05
SHARP 06
SONY 07
SAMSUNG 12
SANYO 13
SEARS 13
TOSHIBA 08
ZENITH 09
TV Brand
Setting
(Ex.) To set Remote to RCA 05:
Press in succession
Hold
down
Release
STOP
JKL
5
POWER
AUX
0
3 –2
Number
TV CH +/–
POWER
TV VOL +/–
ENTER
TV/VCR
2
3 –3
3 –1 3
