54
EN
OTHER USEFUL FUNCTIONS (cont.)
* The default setting is bold in the table below.
Up to four audio signal channels can be input from a DV camcorder
through the DV IN connector (i.LINK). This recorder allows you to select
and record two of these channels. This setting is used to specify which
two channels to record.
When there are four DV audio channels (32kHz):
AUDIO1: Records the two channels (L/R) of DV AUDIO 1.
AUDIO2: Records the two channels (L/R) of DV AUDIO 2.
1+2MIX: Mixes and records both DV AUDIO 1 and 2.
When there are two DV audio channels (48kHz):
Because there are only two channels, those two channels are recorded
regardless of the DV sound setting.
DV AUDIO REC
AUDIO1
AUDIO2
1+2MIX
OPTICAL OUT
Dolby D
2CH-PCM
Audio settings [AUDIO]
S200
DV IN
i.LINK IN/OUT
DIGITAL OUT
OPTICAL
PCM/DOLBY DIGITAL
R
Y
L
P
B/CB
VIDEO
P
R
/C
R
S VIDEO S VIDEO
AUDIO
R
IN
(L-1)
IN(L-2)
L(MONO) VIDEO
REMOTE PAUSE/
AV COMPU LINK
CABLE BOX
ANTENNA
AUDIO
OUT
OUT
OUT
TV
IN
VHF/UHF
IN
Amplifier equipped
with Dolby Digital
decoder
Note for connection:
Remove the connector
cover from the VCR and
the protection cap from
the cable.
This VCR
This VCR can send the Dolby Digital bitstream or PCM Audio to external
devices.
When you play back a tape including the Dolby Digital bitstream, and if
you have a device equipped with Dolby Digital decoder, set this
function to “Dolby D”.
If not, set this function to “2CH-PCM”.
The digital audio is output only when you play back a tape recorded in
D-VHS format. The digital audio is not output when you play back a
tape recorded in S-VHS/VHS format.
When this function is set to “ON”;
If a SAP program is received, the SAP audio is recorded on both the
normal and Hi-Fi tracks. The main audio is not recorded.
If a non-SAP program is received, the main audio is recorded on both
the Hi-Fi and normal tracks.
When this function is set to “OFF”, the SAP audio cannot be recorded.
2ND AUDIO REC
ON
OFF
