1160 LCD unit
For access, remove these FRUs in order:
• “1010 Battery pack” on page 63
• “1020 ExpressCard blank bezel” on page 64
• “1050 DIMM slot cover” on page 69
• “1070 PCI Express Mini Card for wireless WAN” on page 71
• “1080 Keyboard” on page 73
• “1110 PCI Express Mini Card for wireless LAN” on page 81
• “1120 Keyboard bezel assembly, FPC cable, and Bluethooth daughter card” on page 83
Removal steps of LCD unit
1
1
Step Screw (quantity) Color
Torque
1
M2.5 × 6 mm, wafer-head, nylon-coated (2)
Black 0.392 Nm
(4.0 kgfcm)
Chapter 8. Removing and replacing a FRU 93
