MGate EIP3000 Series User’s Manual Configuring the EtherNet/IP Gateway
Parameter Value Notes
Password (an alphanumeric string)
You can set a password to prevent
unauthorized users from configuring the
unit. The password will be required when
anyone attempts to configure the unit
over the network. Modbus operation is
not affected by the password.
Confirm password (an alphanumeric string)
Re-type the password again for
confirmation.
ATTENTION
Both IP1 and IP2 all can be set manually. Since IP1 is the main IP address, please assign the IP2
address to the same network subnet as IP1. If IP2 is assigned a different network subnet from IP1,
an error message will appear. To continue, click OK and set a valid IP address for IP2.
The Gateway will only display a warning message if the Gateway IP address is invalid. However,
you can still click OK to continue.
5-11
