National Instruments Corporation B-1 PCI-6023E/6024E/6025E User Manual
B
Custom Cabling and Optional
Connectors
This appendix describes the various cabling and connector options for the
boards.
Custom Cabling
National Instruments offers cables and accessories for you to prototype
your application or to use if you frequently change board interconnections.
If you want to develop your own cable, however, the following guidelines
may be useful:
• For the analog input signals, shielded twisted-pair wires for each
analog input pair yield the best results, assuming that you use
differential inputs. Tie the shield for each signal pair to the ground
reference at the source.
• You should route the analog lines separately from the digital lines.
• When using a cable shield, use separate shields for the analog and
digital halves of the cable. Failure to do so results in noise coupling
into the analog signals from transient digital signals.
The following list gives recommended part numbers for connectors that
mate to the I/O connector on your board.
Mating connectors and a backshell kit for making custom 68-pin cables are
available from National Instruments (part number 776832-01)
♦ PCI-6023E and PCI-6024E
Honda 68-position, solder cup, female connector
(part number PCS-E68FS)
Honda backshell (part number PCS-E68LKPA)
