NETGEAR MR814v2 Network Router User Manual



Reference Manual for the MR814v2 Cable/DSL Wireless Router
3-2 Wireless Configuration
Implement Appropriate Wireless Security
Unlike wired network data, your wireless data transmissions can extend beyond your walls and
can be received by anyone with a compatible adapter. For this reason, use the security features of
your wireless equipment. The MR814v2 router provides highly effective security features which
are covered in detail in this chapter. Deploy the security features appropriate to your needs.
Figure 3-1: MR814v2 wireless data security options
Restricting access by MAC address filtering adds an obstacle against unwanted access to your
network, but the data broadcast over the wireless link is fully exposed. To block a determined
eavesdropper, you should use one of the data encryption options of the firewall. Wired Equivalent
Privacy (WEP) data encryption provides data security.
Understanding Wireless Settings
To configure the Wireless settings of your firewall, click the Wireless link in the main menu of the
browser interface. The Wireless Settings menu will appear.
Note: Indoors, computers can connect over 802.11b wireless networks at a
maximum range of up to 500 feet. Such distances can allow for others outside of your
immediate area to access your network.
1) Open System: Easy but no security
2) MAC Access List: No data security
3) WEP: Security but some performance impact
Wireless Data
Security Options
Range: Up to 500 Feet
MR814 v2
