CTA 150i card installation
Computer Telephony Adapter 150 Installation Guide
Connecting the CTA 150i card to Norstar
The CTA 150i card does not need a dedicated Norstar phone line. It can share
a phone line with one of the following Norstar phones:
• M7100
• M7208
• M7310 (May be equipped with a busy lamp field)
• M7324 (May be equipped with an attached Central Answering Position)
In addition, the following requirements must be met:
• The line cord that connects the phone to the CTA 150i card must be no
longer than 15 m (50 ft).
• If the telephone line that connects the CTA 150i card to the Norstar KSU
is longer than 304 m (1000 ft), you must install a loop power supply to
provide power to the Norstar telephone when the PC is not on.
• The telephone line that connects the CTA 150i card to the Norstar KSU
must be no longer than 853 m (2800 ft).
Connecting the CTA 150i card to the Norstar KSU:
1. If there is a Norstar phone plugged into the telephone outlet that you
want to use, unplug it.
2. Plug one end of the line cord (provided with the CTA 150i card) into
the telephone outlet.
3. Plug the other end of the line cord into the jack labeled “LINE” on the
CTA 150i card.
4. Plug the Norstar telephone into the jack labeled “PHONE” on the
CTA 150i card.
