Appendix
*14
Only for model with TPM.
For information on TPM,
click
(Start) and input “c:\util\drivers\tpm\index.hta” in [Search programs and fi les] and press
Enter
, and refer to the Installation Manual of “Trusted Platform Module (TPM)”.
*15
Only for model with ExpressCard slot
*16
Only for model with Smart Card slot
*17
SD Memory Cards that support high-speed transfer rates can be used.
Windows ReadyBoost function is also supported.
Operation has been tested and confi rmed using Panasonic SD Memory Cards and SDHC Memory Cards with a capacity of up
to 32
GB
, and Panasonic SDXC Memory Card with a capacity of up to 64
GB
.
Operation on other SD equipment is not guaranteed.
*18
Does not guarantee operation of all USB-compatible peripherals.
*19
The AC adaptor is compatible with power sources up to 240
V
AC adaptor.
The unit for North America (identifi ed by the suffi x ‘M’ on the model number) is supplied with a 125
V
AC compatible AC cord.
20-M-1-1
*20
Measured at LCD brightness: 60
cd/m
2
Varies depending on the usage conditions, or when an external device is attached.
*21
Varies depending on the usage conditions.
*22
Approx. 0.9
W
when the battery pack is fully charged (or not being charged) and the computer is OFF.
<When using with 115
V
AC>
Even when the AC adaptor is not connected to the computer, power is consumed (Max. 0.2
W
) simply by having the AC adaptor
plugged into an AC outlet.
*23
Rated power consumption
23-E-1
*24
Do not expose the skin to this product when using the product in a hot or cold environment. (
page 10)
When using in hot or cold environment, some peripherals may fail to work properly. Check the operation environment of the
peripherals.
Using this product continuously in a hot environment will shorten the product life. Avoid use in these types of environments.
When using in low temperature environment, startup may become slow or battery operation time may become short. The com-
puter consumes power when the hard disk is warming up during startup. Therefore, if you are using battery power and the
remaining power is low, the computer may not start up.
*25
When reinstalling Windows using the data of the recovery area on the hard disk, you can select the OS to be installed (either
Windows 7 (32-bit) or Windows 7 (64-bit)). An OS that has been installed at the time of purchase or an OS that has been in-
stalled using the hard disk recovery function or the recovery disc can be supported.
*26
You need to install to use the feature.
*27
For information on Wireless Manager, refer to the “Supplementary Instructions for Wireless Manager mobile edition 5.5” by the
following procedure.
Click
(Start) and input “c:\util\wlprjct\Supplementary Instructions.pdf” in [Search programs and fi les] and press
Enter
.
*28
Perform on the recovery partition. (If this software can not be performed on the recovery partition, perform from the recovery
disc)
*29
Only for model with Camera.
*30
It does not correspond to IEEE802.11a+b+g+n standards.
Actual speeds may differ.
