37 (GB)
INPUT-A
fH: 31.4KHz
fV: 59.9Hz
H/C-SYNC:POS
V-SYNC:POS
SonG:NEG
INPUT SIGNAL:RGB
INPUT MEMORY No.02
No.11
INPUT
SELECT
PIC
CTRL
INPUT
SETTING
SET
SETTING
INPUT
INFO.
SEL:
SET:
ENTER
EXIT: MENU
n
The INPUT INFO menu displays the information on
the current input signal.
fH (Horizontal frequency)
Indicates the horizontal frequency of the input signal.
This indication is not an absolute value, but is only
used as a reference.
fV (Vertical frequency)
Indicates the vertical frequency of the input signal.
This indication is not an absolute value, but is only
used as a reference.
H/C (Horizontal/Composite)-SYNC
Indicates the polarity of the horizontal or composite
sync signal. When the picture is being projected using
this type of sync signal, the POS (NEG) is displayed in
green. When the picture is being projected without
using this type of sync signal, the POS (NEG) is
displayed in white.
POS: The polarity of the sync signal is positive.
NEG: The polarity of the sync signal is negative.
– – –: No sync signal is input.
V (Vertical)-SYNC
Indicates the polarity of the vertical or composite sync
signal.
When the picture is being projected using this type of
sync signal, the POS (NEG) is displayed in green.
When the picture is being projected without using this
type of sync signal, the POS (NEG) is displayed in
white.
POS: The polarity of the sync signal is positive.
NEG: The polarity of the sync signal is negative.
– – –: No sync signal is input.
SonG (Sync on Green)
Indicates the polarity of the sync on Green. When the
picture is being projected using this type of sync
signal, the NEG is displayed in green. When the
picture is being projected without using this type of
sync signal, the NEG is displayed in white.
NEG: The polarity of the sync signal is negative.
– – –: No sync. signal is input.
INPUT SIGNAL
Displays the type of current input signal.
NTSC 3.58: NTSC
3.58 input signal
PAL: PAL input signal
SECAM: SECAM input signal
NTSC 4.43: NTSC
4.43 input signal
PAL-M: PAL-M input signal
B/W: Black and white input signal
Y/C: S video input signal
RGB: RGB input signal
COMPONENT: Component (Y/R-Y/B-Y, Y/C
B/CR)
input signal
HDTV YPBPR: HDTV YP
BPR input signal
HDTV GBR: HDTV GBR input signal
IDTV: When ON is selected.
The INPUT INFO (Information) Menu
