Configuring the Modem
Page
17
SW2-8
−
Carrier Control (high- & low-speed modes)
SW2-8 ON = Constant
OFF = Switched
SW2-8 selects either constant or switched carrier. Constant carrier
allows DTEs, such as asynchronous dumb terminals or RTUs, to
operate with modems, without the input RTS signal. When constant
carrier mode is enabled (SW2-8 set to ON), the modem forces the
transmit carrier active and the RTS-CTS delay is minimum (<0.5 ms.).
You can use constant carrier in 4-wire, point-to-point or multi-point
applications (from master to slave modems).
In switched-carrier mode (SW2-8 set to OFF), the RTS/CTS delay is 23
ms.
SW 2-9
−
RX Termination (high- & low-speed modes)
SW2-9 ON = Disable Rx Termination
OFF = Enable Rx termination
SW2-9 selects whether RX termination is enabled for a modem. If you
set this switch OFF, the receiver is terminated with 600
Ω
. If you set
this switch ON, the receiver is not terminated.
SW 2-10
−
Ground Option (high- & low-speed modes)
SW2-10
ON = Modem signal ground is connected to chassis ground
OFF = Modem signal ground and chassis ground
disconnected
SW2-10 determines the grounding option for the modem. Setting this
switch ON connects the modem signal ground to chassis ground.
Setting this switch OFF disconnects the modem signal ground from
chassis ground.
