The Tx line of the Shelf’s RJ-45 jack must connect to the Rx line
of the other modem.
For more information, refer to the Telenetics RM16M Installation and
Operation Manual for the Universal Data Shelf version you have.
Mass Termination Connector
As an option, a 50-pin mass-termination connector can be used as the
Telco connection for the modem(s). For more information, refer to the
Telenetics RM16M Installation and Operation Manual for the Universal
Data Shelf version you have.
Connecting an RS-232 Device
The Universal Data Shelf has different RS-232 options for accepting an
attached RS-232 (RTU) device. Your version may have a female, 25-
pin RS-232 connector for each slot in the Shelf. It may also have an
optional 50-pin mass-termination Telco connector. For more
information, refer to the Telenetics RM16M Installation and Operation
Manual for the Universal Data Shelf version you have.
