Chapter Title—Attribute Reference
Hardware
The SLVP089 Synchronous Buck Converter Evaluation Module (SLVP089)
provides a method for evaluating the performance of the TL5001 pulse-width-
modulation (PWM) controller. The device contains all of the circuitry necessary
to control a switch-mode power supply in a voltage-mode configuration. This
manual explains how to construct basic power conversion circuits including
the design of the control chip functions and the basic loop. This chapter in-
cludes the following topics:
Topic Page
1.1 Introduction 1–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Schematic 1–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3 Input/Output Connections 1–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.4 Board Layout 1–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.5 Bill of Materials 1–7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.6 Test Results 1–8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 1
