WORD 86: Features / Command sets enabled
bit 15-14 Reserved
bit 13 1=FLUCH CACHE EXT command supported
bit 12 1=FLUSH CACHE command supported
bit 11 1=Device Configuration Overlay supported
bit10 1=48-bit Address feature set supported
bit 9 1=Automatic Acoustic Management feature set enabled
bit 8 1=SET MAX security extension enabled by SET MAX SET PASSWORD
bit 7 Reserved
bit 6 1=SET FEATURES subcommand required to spin-up after power-up
bit 5 1=Power-Up In Standby feature set enabled
bit 4 Removable Media Status Notification feature set enabled
bit 3 Advanced power Management feature set enabled
bit 2 CFA feature set enabled
bit 1 WRITE / READ DMA QUEUED command supported
bit 0 DOWNLOAD MICROCODE supported
The default value for this WORD is 3C09h.
WORD 87: Features / Command sets enabled
bit 15 0 (Fixed)
bit 14 1 (Fixed)
bit 13 1 (Fixed)
bit 12-6 Reserved
bit 5 1=General Purpose Logging feature set supported
bit 4 Reserved
bit 3 1=Media Card Pass Through command feature set enabled
bit 2 1=Media serial number is valid
bit 1 1=SMART self-test supported
bit 0 1=SMART error logging supported
The value for this WORD is 6023h.
WORD 88: Mode information for Ultra DMA
The active mode reflects the command change.
bit 15-8 Active transfer mode
bit 13 1=Mode 5 is active
bit 12 1=Mode 4 is active
bit 11 1=Mode 3 is active
bit 10 1=Mode 2 is active
bit 9 1=Mode 1 is active
bit 8 1=Mode 0 is active
bit 7-0 Supported mode
bit 5 1=Mode 5 is supported
bit 4 1=Mode 4 is supported
bit 3 1=Mode 3 is supported
bit 2 1=Mode 2 is supported
bit 1 1=Mode 1 is supported
bit 0 1=Mode 0 is supported
The default value for this WORD is 003Fh
WORD 89: The time period for Security Erase Unit command completion shall be set.
TIMER
A
CTUAL VALUE
0 Not s
p
ecified
1-254
(
Timer 2
)
minuites
255 > 508 minuites
