XEROX WIDE FORMAT 510dp OPERATOR MANUAL vii
Introduction
Congratulations on acquiring your new XEROX Wide Format
510dp. Xerox looks forward to supporting you and helping you
increases your printing productivity.
The XEROX Wide Format 510dp is available as a standalone
printer with an AccXES controller or as a multifunction device with
a Synergix Scan System and an AccXES controller. The Synergix
Stacker and a full-featured Folder are optional accessories for
either configuration.
The printer, depending on the option installed, has a throughput of
5, 7 or 10 D-size (A1) prints per minute at a process speed of 4.5
inches per second. Depending on the selected options, it is
equipped with one, two, or three media drawers that can hold roll
media from 11 to 36 inches wide and up to 500 feet long. An
optional sealed media drawer is available in place of standard
media drawers for locations that experience humidity extremes.
For jobs requiring non-standard media sizes, the printer has a cut
sheet feed-in shelf that enables you to bypass the media drawers.
It also has a standard catch tray that can accommodate up to 100
prints of all sizes.
Organization and content of this manual
The XEROX Wide Format 510dp Operator Manual provides the
information you need to become familiar with the components,
features operation, and specifications of your printer. It contains
the following chapters:
Chapter 1 Printer overview
This chapter shows the orientation of the printer. It illustrates and
describes the main components of the printer and the control
panel.
Chapter 2 Powering on and off
This chapter provides instructions for powering on and powering
off and explains the power consumption modes of the printer.
Chapter 3 Media
This chapter explains what happens when a media roll empties,
how to load a media roll, and how to specify the size and type of a
media roll. It provides the procedure for using cut sheet media
and describes the automatic roll-switching feature. Additionally, it
lists some tips for storing your media.
Chapter 4 Off-line Setup Menu
This chapter lists the Setup Menu options and provides detailed
instructions for using the Printer Menu sub-option.
