FreeFlow Scanner 665E Getting Started
1-5
1. Overview
Scanner hardware overview
The Xerox FreeFlow Scanner 665E is a high quality, high volume
scanner. Teamed with scanning software and a personal
computer, the scanner is a powerful tool for capturing and
manipulating graphics and text.
Scanner components
The scanner is comprised of the following components:
Control panel: Use these controls to start and stop scans as well as monitoring
the status of the scanner.
Power switch: The on/off switch is located on the rear of the right side panel.
When you switch on the power, a yellow status LED on the control
panel begins to flash. Wait until the scanner makes an audible
"click" sound and the green status LED lights before turning on
power to the PC.
For more information about powering on/off the system, refer to
page 1-9.
Automatic Document
Feeder (ADF):
The ADF enables you to scan 1-sided and 2-sided documents
quickly, and returns them in a stack in the same order you placed
Control panel
Power switch
