Reference
BTS Laptop Utility Program Windows
Chapter 5
O:\Manuals\E6385A_Amps\Book\Reference.fm
114
Figure 5-16 Short-Form Test Results Example
Test Results Window
The Test Results window displays test results. These results may be saved for later use
(see Figure 5-17 for an example of the display).
The test results are sent to the PC automatically and displayed in the window. By
selecting File, Logging Enabled, you may enter a file name to save the test results to a
file that may be retrieved into a text editor and printed out. This selection must be
done before the test results are sent to the screen.
Figure 5-17 Test Results Example
