Performing Tests
Single Radio Test
Chapter 4
O:\Manuals\E6385A_Amps\Book\perftst.fm
70
For AMPS Setup Radios:
—Set the Configuration Status to Active to test a radio while it is in service, or
select Configured to take the radio out of service for testing.
— Enter the Channel Number for the setup radio.
— Enter the Setup ID# (number) for the setup radio.
— Enter the CSAC (Control Setup Attenuation Code) for the setup radio.
—Set the Send Commands to MSC field to YES for automated testing using a PC, or NO to
control the Base Station using another method.
Step 4. Press the
k1 [Run] key to begin the test.
Step 5. Follow the on-screen prompts and setup diagram to complete the testing.
Review the Results
The Test Software will display test results for the radio as it tests. It provides prompts at
the top of the display to indicate the measurement or action currently being performed.
See Figure 4-5.
Figure 4-5 Partial Single Radio Test Results for AMPS Radio
Measurement or
action in progress.
