Step 5. Connect the Test Set to the Base Station as indicated and perform any other operations
as prompted. Press the
k1 (Proceed) key to continue after each setup.
• Full calibration requires two separate measurement setups. Make certain to use the
correct test cables for each setup.
• Partial calibration uses one measurement setup. Make certain to use the Base
Station TX Test Port cable when making the measurement.
Review the Results
The Test Software will calculate and display the Base Station TX Test Port coupling
factor. You should write this value next to the TX Test Port for future reference.
Press the
k1 (Proceed) key to return to the Calibration/Utilities Menu screen, then press
the
k5 (Return) key to return to the Lucent AMPS Test Main Menu screen.
If you then select the Base Station Configuration field (from the Lucent AMPS Test
Main Menu screen), you will note that the TX Test Port Coupling Factor [dB] field
for the specified antenna now contains the value determined by the test.
