Single Radio Test
This test measures several aspects of a single radio. When the test is run, a setup screen
is displayed to specify information about the radio you want to test.
The measurements made on each radio depends on its type: AMPS or AMPS Setup. The
radio type is specified on the setup screen at the start of the test.
This test can be performed with the Base Station in service using the Base Station TX
Test Port, or performed out-of-service using the Base Station TX Antenna Port (see
“Which Test Set Port to Use – ANT IN or RF IN/OUT?” on page 35 and “Base Station
Configuration” on page 39).
The following measurements are made on AMPS radios:
• TX Frequency Error
• TX Power (at a specific power amplifier step)
• TX RMS Residual FM
• TX Average Peak Deviation @
−
16 dBm
• TX Distortion @
−
16 dBm
• TX Peak (+) Deviation @ 0 dBm
•TX Peak (
−
) Deviation @ 0 dBm
• TX SAT Average Peak Deviation @ 5970 Hz
• TX SAT Frequency Error @ 5970 Hz
• TX SAT Average Peak Deviation @ 6000 Hz
• TX SAT Frequency Error @ 6000 Hz
• TX SAT Average Peak Deviation @ 6030 Hz
• TX SAT Frequency Error @ 6030 Hz
• TX Peak (+) Data Deviation
• TX Peak (-) Data Deviation
The following measurements are made on AMPS Setup radios:
• SU TX Frequency Error
• SU TX Power (at a specific power amplifier step)
• SU Peak Data Deviation
