7.2.4 Description – P240
This is a user defined alpha-numeric parameter. Any string up to 12 characters long may be entered using the
keypad. This will usually be a description of the application.
The following characters are allowed:
!”#$%&’()*+,-./0123456789:;<=>?@ABCDEFGHIJKLMNOPQRSTUVWXYZ[\]^_
Parameter values:
Default Min Max
CLARIFIER1 - -
7.3 De-sludge parameters
The following parameters relate to the de-sludge function and are found in the setup menu.
Note that minimum and maximum parameters relating to time are 00:00 and 23:59 respectively. Minimum and
maximum parameters relating to sludge level are 0.000 to 7.000m (0.00 to 23.00 feet)
Note: A full menu structure is shown in section 11.
7.3.1 Start On - P250
Use this parameter to select how the de-sludge cycle starts.
The selectable options are:
x None
x Time
x Sludge Level
The parameter defaults to “None” which means it is not used.
Parameter values:
Default Min Max
None - -
7.3.2 Stop On - P251
Use this parameter to select how the de-sludge cycle stops.
The selectable options are:
x None
x Time
x Sludge Level
The parameter defaults to "None" which means it is not used.
Parameter values:
Default Min Max
None - -
