5. Check the Enable Wireless Client Association radio box to allow wireless clients access to
this wireless access point.
6. Click Apply to save your changes.
To delete a remote AP from the list, click Delete adjacent to the AP’s MAC address in the Wireless
Remote Access Point List.
The following figure illustrates a multi-point bridge setup over three LAN segments.
To configure wireless access points in a multi-point configuration:
1. Set the Operating Mode of the three Wireless APs as follows:
• Configure AP2 on LAN Segment 1 in Point-to-Point Bridge Mode. Enable Wireless Client
Association and add the Remote MAC Address of AP1 on LAN Segment 2.
• Because it is in the central location, configure AP1 on LAN Segment 2 in Multi-Point
Bridging mode. Enable Wireless Client Association and add the MAC addresses of the
adjacent Point-to-Point APs (AP2 and AP3).
• Configure AP3 on LAN 3 in Point-to-Point Bridge mode. Enable Wireless Client
Association and add the Remote MAC Address of AP1 on LAN Segment 2.
2. Verify the following parameters for all three wireless access points:
Figure 4-4
AP2
AP1
AP3
LAN
Segment 1
LAN
Segment 2
LAN
Segment 3
PCs
PCs
PCs
Router
Hub or Switch
Hub or Switch
Wireless PC Card
in a Notebook Computer
192.168.0.1
Internet
Point-to-Point
Bridge Mode
Point-to-Point
Bridge Mode
Multi-Point
Bridge Mode
