A-1
v1.0, June 2007
Appendix A
Default Configuration and Technical
Specifications
Default Configuration Settings
You can use the reset button located on the front of your device to reset all settings to their factory
defaults. This is called a hard reset.
To perform a hard reset, push and hold the reset button for approximately 5 seconds (until the
TEST LED blinks rapidly). Your device will return to the factory configuration settings shown
in Table A-1 below.
Pressing the reset button for a shorter period of time will simply cause your device to reboot.
Table A-1. Access Point Default Configuration Settings
Feature Description
AP Login
User Login URL 192.168.0.227
User Name (case sensitive) admin
Login Password (case sensitive) password
Access Point Name NETGEARxxxxxx where xxxxxx are the last six digits of
the WG602v4 MAC address
Ethernet Connection
Ethernet MAC Address See bottom label.
Port Speed 10/100
Local Network (LAN)
Lan IP 192.168.0.227
Subnet Mask 255.255.255.0
DHCP Client Enabled
