65 Chapter 6
Parts
PARTNAME DESCRIPTION ACER PART NO.
BOARD
DAUGHTER BOARD USB/AUDIO USB BOARD 55.S46VF.001
MAINBOARD
MB FG965M FOR P4 LGA775 CPU INTEL
G965+ICH8DH DDR2 Gigabit LAN HD
codec W/I 1394 W/I CPU RM
FG965M MB.S5909.002
"MB FG965M FOR P4 LGA775 CPU
INTEL G965+ICH8DH DDR2 Gigabit LAN
HD codec W/I 1394, CPU RM, I/O
SHIELDING (4 USB PORTS)"
FG965M MB.S5909.001
CARD READER
"KYE CARD READER+1394+IR,
CR503U2, W/I HOUSING, W/I 1394
CABLE+USB CABLE"
CR503U2-5101 PZ.CR50J.001
"KYE CARD READER+1394+IR,
CR503U2, W/I HOUSING, W/I 1394
CABLE+USB CABLE"
CR503U2-5111 PZ.CR50J.003
RF RECEIVER
LOGITECH WIRELESS BOARD LOGITECH WIRELESS BOARD RV.GPY01.005
LOGITECH WIRELESS RECEIVER LOGITECH WIRELESS RECEIVER RV.GPY01.006
CABLE
POWER SWITCH/ HDD /LAN LED CABLE POWER SWITCH/ HDD /LAN LED
CABLE
50.S55VF.001
HDD CABLE SATA_1 "SATA-HDD DATA CABLE, ROHS" 50.S46VF.001
SERIAL ATA DATA CABLE FOR ODD SERIAL ATA DATA CABLE FOR ODD 50.P37VF.001
SERIAL ATA POWER CABLE FOR ODD SERIAL ATA POWER CABLE 50.P37VF.002
USB CABLE "USB CABLE (460MM) , ROHS" 50.S46VF.002
AUDIO CABLE "AUDIO CABLE (560MM), ROHS" 50.S46VF.004
IDE FDD CABLE 34PIN "FDD DATA CABLE, ROHS" 50.S46VF.007
SPDIF BOARD W/ CABLE SPDIF BOARD W/ CABLE 55.S46VF.002
LED CABLE FOR THE LOGO LED CABLE FOR THE LOGO 50.S46VF.005
IR CABLE IR CABLE 50.S46VF.006
CASE/ COVER/ BRACKET ASSEMBLY
"FRONT BEZEL W/ POWER BUTTON,
5.25"" 3.5"" EMPTY COVER"
A451 BEZEL ASSY 60.S46VF.001
POWER BUTTON POWER BUTTON 42.S46VF.001
ODD COVER 1 W/ HOLDER A451 ODD-UPPER DOOR W/
HOLDER
42.S46VF.002
ODD COVER 2 W/ HOLDER A451 ODD-LOWER DOOR W/
HOLDER
42.S46VF.003
TOP COVER ASSY TOP COVER ASSY 60.S46VF.002
FRONT COVER WITH ACER LOGO FRONT COVER WITH ACER LOGO 60.S46VF.003
"FILLER COVER FOR 3 1/2"" DEVICE" "3.5"" FILLER PANEL" 42.S46VF.009
