ADDERVIEW CATx 1000
Computer Port
Computer 1 01
Computer 2 02
Computer 3 03
Computer 4 04
Computer 5 05
Computer 6 06
Computer 7 07
Computer 8 08
User Status
ADMIN SHARED USE
F1-More menus F3-Find
Esc-Quit F4-Logout
Configuration menus
The configuration menus allow you to determine many aspects of the
AdderView CATx 1000 capabilities. From here you can:
• Create individual user accounts and determine access rights,
• Provide names for all connected computers to allow quick recognition,
• Set individual and global settings for users,
• Run various functions, such as mouse restore operation,
• Save and load AdderView CATx 1000 configuration settings, and more.
To access the configuration menu
1 If the main menu is not already displayed, press and hold and then
press using a keyboard attached to a AdderView CATx 1000 user port.
The main menu will be displayed:
3 Use the
and keys to highlight an option, then press to select.
ADDERVIEW CATx 1000
Configuration Menu
Functions
User Preferences
Global Preferences
Setup Options
Edit Computer List
Edit User List
EditAutoscan List
Enter-Select
F1-More menus
Esc-Quit
FirmwareVersion 1.01b06
Default names for
each computer port
Assistance for
keypress options
Your Login name
Connection status
Port numbers
2 Press To display the Configuration Menu:
Hotkeys
Note: and are the standard hotkeys and can be altered to
avoid clashes with other devices or software. If you change the hotkeys,
remember to use the new ones in place of and when following
the instructions in this guide.
Security
Note: If the security option has been
enabled, you will be asked for a valid
user name and password before the
main menu can be displayed.
IMPORTANT: When supplied, AdderView CATx 1000 units have
their security features disabled, which means that any attached
users have access to all connected computers and all AdderView
CATx 1000 settings. You are strongly recommended to enable
the ‘Security’ feature and set an access password for the ADMIN
account.
ADDERVIEW CATx 1000
User Name:
Password:
Esc-Scr Save
Availability of each
computer:
Green - available
Red - unavailable
