ADDERVIEW CATx 1000
User Name:
Password:
Esc-Scr Save
ADDERVIEW CATx 1000
Computer Port
Computer 1 01
Computer 2 02
Computer 3 03
Computer 4 04
Computer 5 05
Computer 6 06
Computer 7 07
Computer 8 08
User Status
ADMIN SHARED USE
F1-More menus F3-Find
Esc-Quit F4-Logout
This column shows
the AdderView CATx
1000 address for
each computer. If you
wanted to select ports
using the hotkey
method, these are
addresses that you
would enter.
Default names for
each computer port
Your Login name
Link status of your
user port
Enter your Login
name here
Selecting a computer
There are three main ways for local and remote users to select a specific
computer channel:
• Using hotkeys (as described below) – this is a good method if you continually
access a small number of computers.
• Using the on-screen menu – this is the best method when there are many
connected computers.
• Using mouse buttons – this is a good method for cycling between a small
number of computers.
For all methods (if the confirmation box option is enabled), when the required
port is selected, a pop up message will be displayed to confirm the computer
name or number, and its status. Alternatively, an error message explaining why a
connection is not possible (press to cancel the latter type of message).
To select a computer using hotkeys
1 Simultaneously press and hold and .
Note: The and keys when pressed in combination are called
‘hotkeys’ and they signal to the AdderView CATx 1000 that you wish to
control it, rather than the computer. However, if these particular hotkeys
clash with another device or program, then your administrator may change
them to a different combination. If the combination fails to work,
then please contact the system administrator for details.
2 While still holding and , press the first numeral of the required port
address, then:
• If the port address is a single character, release all of the keys.
• If the port address is two or more characters, release the first numeral
key and press the second – repeat this procedure until all of the port
address numerals have been entered, then release and .
Note: The numbers on your keyboard’s numeric keypad are not valid, use
only the numeral keys above the QWERTY section.
Note: If your user port does not have authorisation to view the selected port
then an ‘Insufficient user rights’ messages will be displayed.
continued
If the above login prompt is not displayed, you
are either already logged in to the AdderView
CATx 1000 unit, or the security features have not
been implemented. In such cases see ‘To view this
menu at any time’ below.
Operation
Local and remote user access
Local users (directly connected) and remote users (via an Adder X100/X200
extender) gain access to the AdderView CATx 1000 unit in exactly the same way.
To gain access as a local or remote user:
1 From a local or remote keyboard, press any key to display the login prompt:
2 Enter your username and password. Providing you have the correct
permissions, the screen will display the main menu, showing you a list of
computers for which you have permission to access:
To view this menu at any time: Press and hold the hotkeys (usually and ),
then press and finally release all three keys.
Note: The and keys when pressed in combination are called ‘hotkeys’
and they signal to the AdderView CATx 1000 that you wish to control it, rather
than the host computer. However, if these particular hotkeys clash with another
device or program, then your administrator may change them to a different
combination. If the combination fails to work, then please contact
your system administrator for details.
These indicators show
which systems are
currently accessible
(green) or inaccessible
(red).
