4 Agilent U1251A/U1252A User’s and Service Guide
1 Getting Started Tutorial
Adjusting the tilt-stand
To adjust the meter to a 60° standing position, pull the
tilt- stand outwards to its maximum reach.
Figure 1-1 Tilt-stand at 60
°
To adjust the meter to a 30° standing position, bend the tip
of the stand so that it is parallel to the ground before
pulling the stand outwards to its maximum reach.
Figure 1-2 Tilt-stand at 30
°
IR-USB cable
To PC (host)
Tilt-stand at 60 °
IR-USB cable
To PC (host)
Tilt-stand at 30 °
