Getting Started Tutorial 1
Agilent U1251A/U1252A User’s and Service Guide 21
for U1252A
(AC + DC Voltage)
DC mV
AC mV
AC + DC mV
Ω
(Resistance)
Ω
Ω
nS
(Diode Test and Frequency)
Diode
Hz
/ TEMP
(Capacitance and Temperature)
Capacitance
Temperature
(AC Current)
DC μA
AC μA
AC + DC μA [for U1252A]
(DC Current)
DC mA
AC mA
AC + DC mA
%(0–20 or 4–20)
(AC + DC Current)
DC A
AC A
AC + DC A [for U1252A]
(Square wave output for U1252A)
Duty cycle (%)
Pulse width (ms)
Notes for selecting display with the Shift button:
1 Press to switch between dBm and dBV measurement.
Press for more than 1 second to return to AC V measurement only.
Table 1-9 Selecting display with the Shift button
