Attaching IEEE 802.11b Interface Unit
• Do not touch the inside of the controller board compartment. Doing so may cause a machine
malfunction or a burn.
• Before handling the IEEE 802.11b interface board, ground yourself by touching something metal to
discharge any static electricity. Static electricity can damage the IEEE 802.11b Interface board.
• Do not subject the 802.11b interface unit to physical shocks.
1. Check the package contains the following:
IEEE 802.11b Interface Unit
AUB247S
1. Interface Unit
2. Card
3. Antenna
4. Antenna Cap
2. Turn off the power of the printer, and then unplug the power cable and the interface cable.
Attaching IEEE 802.11b Interface Unit
33
2
