3. HARDWARE SETUP
3.2 Layout Contents
Motherboard Settings
1) DIP_SW 6–10 p. 18 CPU External Frequency Selection
2) DIP_SW 2–5 p. 19 CPU Core:BUS Frequency Multiple Selection
Expansion Slots/Sockets
1) System Memory p. 20 System Memory Support
2) DIMM1, DIMM2 p. 22 DIMM Memory Module Support
3) SLOT-1 p. 23 CPU Support
4) PCI1, PCI2, PCI3 p. 27 32-bit PCI Bus Expansion Slots
5) AGP p. 28 Accelerated Graphics Port
Connectors
1) PS2KBMS p. 29 PS/2 Mouse Port Connector (6 pin-female)
2) PS2KBMS p. 29 PS/2 Keyboard Port Connector (6-pin female)
3) USB p. 30 Universal Serial Bus Connectors 1 & 2 (Two 4-pin female)
4) PRINTER p. 30 Parallel Port Connector (25-pin female)
5) COM1 p. 30 Serial Port Connector (9-pin male)
6) 1394_CON p. 31 1394 Connector (6-pin male)
7) GAME_AUDIO p. 31 Joystick/MIDI Connector (15-pin female) (optional)
8) GAME_AUDIO p. 31 Audio Port Connectors (Three 1/8” female) (optional)
9) PRIMARY IDE p. 32 Primary/Secondary IDE Connectors (Two 40-1 pins)
SECONDARY IDE
10) FLOPPY p. 32 Floppy Drive Port Connector (34 pins)
11) CHA_, PWR_, CPU_FAN p. 33 Chassis, Power Supply, CPU Fan Connectors (3 pins)
12) WOL_CON p. 34 Wake-On-LAN Connector (3 pins)
13) WOR p. 34 Wake-On-Ring Connector (2 pins)
14) 1394HEAD2/3 p. 35 IEEE-1394 Headers (Two 8-pin male) (optional)
15) MODEM, AUX_CON, p. 35 Internal Audio Connectors (Four 4 pins)
CD_IN, VIDEO
16) MLED (PANEL) p. 36 System Message LED (2 pins)
17)
KEYLOCK (
PANEL
)
p. 36 Keyboard Lock Switch Lead (2 pins)
18) SMI (PANEL) p. 36 System Management Interrupt Lead (2 pins)
19) SPEAKER (PANEL) p. 36 System Warning Speaker Connector (4 pins)
20) PWR (PANEL) p. 36 ATX / Soft-Off Switch Lead (2 pins)
21) IDELED (PANEL) p. 36 IDE Device Activity LED (2 pins)
22)
PLED (
PANEL
)
p. 36 System Power LED Lead (3 pins)
23) RESET (PANEL) p. 36 Reset Switch Lead (2 pins)
24) ATXPWR p. 37 ATX Power Supply Connector (20 pins)
25) COM2 p. 38 Serial Port Header (10 pins)
26) SPDIFOUT p. 38 Digital Audio Interface (3 pins)
Layout Contents
