3-22 ASUS Pocket Wireless Access Point (WL-330)
Configuration
WDS setup
To setup a Wireless Distribution System network:
1. Set the AP mode to Hybrid-Active.
2. Enter the MAC address(es) of the target AP(s) you wish to bridge with the
ASUS Pocket Wireless AP in the MAC address list.
3. Specify the channel to be used. All target AP(s) must specify the same
channel to establish connection to the ASUS Pocket Wireless AP.
4. Click Launch.
Typical WDS network
WB2
WB4
WB1
WB3
WB5
In a typical WDS network, the
ASUS Pocket Wireless AP serves
as a central link to all connected
APs (functioning as wireless
bridge). The APs communicate with
each other using the central AP,
while maintaining network
connections to their respective
wireless clients.
In this setup, WB4 and WB5 may
communicate using point-to-point
connection but WB5 may not
communicate with the ASUS Pocket
Wireless AP, WB1, WB2, and WB3
since multipoint-to-point connection
is not supported.
