Section 3: Setup for NetWare
26 Axis NPS 530/532 User’s Manual
NetWare 4.xx: 1. Select Print Servers from the PCONSOLE Main Menu.
2. Select the NetWare Print Server to which you want to link your
NPS 530/532.
3. Select Printers.
4. Press <Insert> to add a remote printer to the Defined Printers list.
5. Type
AXIS<nnnnnn>!n
at the Printer: prompt.
(see notes below)
<
nnnnnn> are the last six digits of the NPS 530/532 serial number,
and n is the logical printer number 1–8.
6. Select AXIS<nnnnnn>!n.
Important: Always use printer numbers 1 and higher; the NPS 530/
532 will not detect any remote printers with printer number 0.
7. Make a note of the NetWare print server name and the Printer
number; you will need it later during the configuration.
8. Select Printer type: , and change to
Other/Unknown
.
9. Select Print Queues Assigned, then press <Insert>
10.Press <Insert>, then select the queue you want to use from the Avail-
able Print Queues list. Repeat this step if you want more than one
queue.
11.Press <F10> to save the changes, then press <Esc>.
12.Press <Esc> to get back to the Main Menu, then exit PCONSOLE.
Repeat this procedure for each file server and print server using the NPS
530/532.
Notes: 1. If the serial number of your NPS 530/532 is 00408C110086
, then
the default name is AXIS110086
. The serial number is found on the
label at the back of the NPS 530/532.
2. You may change the default name using AXCFG, the Axis Configura-
tion Software. This must be done before running PCONSOLE.
3. You may define up to eight remote printers, each attached to its own
NPS 530/532 logical printer. Each remote printer must have a unique
name distinguished by the !n extension.
