User Guide TECHNICAL DATA
MGP D5 53
RS-232 in RS-232 out
9 PIN DSUB FEMALE
1NC
2RXD
3TXD
4NC
5GND
6NC
7NC
8NC
9 PIN DSUB MALE
1NC
2TXD
3RXD
4NC
5GND
6NC
7NC
8NC
Audio out RC in
Black
3.5 mm mini jack
TIP: R
STIM: L
RING: GND
3.5 mm stereo mini jack
TIP: 5V DC
RING: SIGNAL
STEM: GND
Audio in 1 Audio in 1
Black
3.5 mm mini jack
TIP: R
STIM: L
RING: GND
Black
3.5 mm mini jack
TIP: R
STIM: L
RING: GND
USB LAN
DIGITAL USB
1VCC
2-Data
3+Data
4GND
1TX+
2TX-
3RX+
4GND
5GND
6RX-
7GND
8GND
