DO NOT connect the Parallel or USB
cable yet.
1
Make sure that the power switch is off.
Connect the power cord to the MFC.
2
Plug the power cord into an AC outlet. Turn
the power switch on.
3
Connect one end of the telephone line cord
to the jack on the MFC marked LINE and the
other end to a modular wall jack.
Warning
■ The MFC must be grounded using a 3-prong plug.
■ Since the MFC is grounded through the power
outlet, you can protect yourself from potentially
hazardous electrical conditions on the telephone
network by keeping the power switched on when
you connect it to a telephone line. Similarly, you
can protect yourself when you want to move your
MFC by disconnecting the telephone line first and
then the power cord.
5
Installing the Power
Cord and Phone Line
Power Cord
If you are sharing one phone line with an
external telephone, connect it as shown
below.
If you are sharing one phone line with an
external telephone answering device,
connect it as shown below.
Please set the receive mode to External
TAD.
For more details, see “Connecting the
MFC” in Chapter 1 of the User’s Guide.
TAD
TAD
