Chapter 8
58
MFC-8860DN and MFC-8870DW: 8
a Press Menu, 2, 3, 1.
23.Set Quick-Dial
1.One-Touch Dial
One-Touch:
Select One-Touch
b Press the One-Touch key where you
want to store a number.
c Press a or b to select Fax/Tel,
E-Mail or IFAX. Press OK.
d Choose one of the options below:
Enter the number (up to 20
characters) if you selected Fax/Tel.
Press OK.
Enter the E-mail address (up to 60
characters) if you selected E-Mail
or IFAX. Use the chart on Entering
Text on page 157 to help you enter
letters. Press OK.
Note
If you selected E-Mail and save the
E-mail address, you can only use the
E-mail address when you are in Scan
mode. If you selected IFAX and save the
E-mail address, you can only use the
E-mail address when you are in Fax
mode.
e Choose one of the options below:
Enter the name using the dial pad
(up to 15 characters). Press OK.
Press OK to store the number or
E-mail address without a name.
f If you want to save a fax/scan resolution
along with the number, choose one of
the options below:
If you selected Fax/Tel in c, press
a or b to select Std, Fine, S.Fine
or Photo.
Press OK and then go to h.
If you selected E-Mail in c, press
a or b to select B/W200dpi,
B/W200x100dpi, Color150dpi,
Color300dpi, or Color600dpi.
Press OK and then go to g.
If you selected IFAX in c, press a
or b to select Std, Fine or Photo.
Press OK and then go to h.
Press OK if you don’t want to change
the default resolution. Go to h.
g Choose one of the options below:
If you selected Black & White in f,
select the file format (TIFF or PDF) that
will be used to send to your PC.
If you selected Color in f, select the file
format (PDF or JPEG) that will be used
to send your PC.
h Choose one of the options below:
To store another One-Touch number
go to b.
To finish storing One-Touch
numbers press Stop/Exit.
Note
• When you do a broadcast and you have
saved a scan profile along with the
number or E-mail address, the scan profile
of the One-Touch, Speed-Dial or Group
number you chose first will be applied to
the broadcast.
• When you create a group or broadcast
using Scan to E-mail only B/W200x100
and B/W200dpi are available. The file
format can be TIFF or PDF.
