The P-touch Editor application makes it easy for anyone to design and print labels for almost
any need imaginable.
On an IBM PC-Compatible Computer
To Start Up P-touch Editor:
• By clicking the P-touch Editor icon:
• Double-click the “P-touch Editor 3.1” icon in the “P-touch Editor 3.1” group window.
• With the Start button:
1 Click the Start button in the taskbar to display the Start menu.
2 Select “Programs”.
3 Select “P-touch Editor 3.1”.
4 Click “P-touch Editor 3.1”.
• With Windows Explorer:
1 Start up Windows Explorer.
2 Select the drive and directory where P-touch Editor is installed.
3 Double-click “Ptedit3.exe”.
After P-touch Editor is started, the following window is displayed.
STARTING P-TOUCH EDITOR
Title bar
Rulers
Cursor
Menu bar
Standard toolbar
Property dock
Layout area
Draw toolbar
Print area
Object dock
Status bar
