3-15
Cisco Performance Visibility Manager User Guide
OL-8620-03
Chapter 3 Monitor
Real-Time Charts
This section contains the following topics:
• Variables Available for Real-Time Monitoring, page 3-15
• Displaying a Real-Time Chart, page 3-16
Variables Available for Real-Time Monitoring
Variables are displayed for individual statistics as rates in units per second (such as PACKETS/SEC).
This rate reflects the change in the selected variable value over time. Table 3-4 shows the real-time
variables that you can monitor for the different statistics available in Cisco PVM tabular reports.
Table 3-4 Available Variables for Real-Time Charts
Statistic Type Available Variables (units/sec)
Application Statistics Packets
Bytes
Hosts (IP) Statistics In Packets
In Bytes
Out Packets
Out Bytes
Non-Unicast Packets
Hosts (MAC) Statistics In Packets
Out Packets
In Bytes
Out Bytes
Multicast Packets
Broadcast Packets
Conversation Packets
Bytes
DSCP Statistics Application Packets
Application Bytes
DSCP Application Statistics Application Packets
Application Bytes
DSCP Host Statistics In Packets
In Bytes
Out Packets
Out Bytes
