Chapter 3 Monitor
Monitor Navigation
Note For samples and descriptions of individual reports, see Appendix B, “Report Samples for Monitor and
Reports.”
Overview
When the Monitor GUI opens, the display defaults to Overview, which automatically displays in graphic
format the TopN hosts, DSCP applications, and active applications monitored for a given Data Source
Group (DSG). The data view defaults to All NAM; you can choose another data view from the
parameters pane and click Run to refresh the Overview display with the new view.
Figure 3-3 displays a sample Overview report.
Switch/Router
• Interface
• Ethernet Traffic
• Ethernet Error
Displays the:
• Port name, in/out bytes, in/out packets, in/out Non-Unicast packets, in/out
discards, in/out errors, and percentage in/out utilization.
• Bytes, packets, broadcast packets, and multicast packets.
• Dropped events, CRC align errors, under- and oversize packets, fragments,
jabbers, and collisions.
VLANs
• VLAN ID
• VLAN Priority
Displays data on the VLAN ID, errors, packets, bytes, non-unicast packets, and
non-unicast bytes collected.
Table 3-1 Report Suites (continued)
Suite Available Reports Description
