3-16
Cisco Performance Visibility Manager User Guide
OL-8620-03
Chapter 3 Monitor
Real-Time Charts
Displaying a Real-Time Chart
To display a real-time chart, complete the following steps:
Step 1 Run a tabular report using either Data Source or All NAM views, and look at the hyperlinks available on
the left side of the report pane.
Step 2 Click the R hyperlink, next to the report element whose real-time data you want to view, as shown in
Figure 3-14.
Switch/Router: Interface
Statistics
In Packets
In Bytes
Out Packets
Out Bytes
Incoming Non-Unicast Packets
Outgoing Non-Unicast Packets
Discarded Ins
Discarded Outs
In Errors
Switch/Router: Ethernet Traffic
Statistics
Bytes
Packets
Broadcast Packets
Multicast Packets
Switch/Router: Ethernet Error
Statistics
Drop Events
CRC Errors
Oversize Packets
Undersize Packets
Jabbers
Fragment Counts
Number of Collisions
VLAN ID Statistics Packets
Bytes
Non-Unicast Packets
Non-Unicast Bytes
VLAN Priority Statistics Packets
Bytes
Table 3-4 Available Variables for Real-Time Charts (continued)
Statistic Type Available Variables (units/sec)
