27
Printer Operation
Menu Setup Mode
If the printer power is turn on while the MODE/REPEAT key is pressed, the
printer enters menu setup mode. In this mode, the printer’s configuration
can be changed using the VuePrint Menu System. During menu setting mode,
the PRINT LED and CONDITION LED are on. Media must be installed in the
printer to use the VuePrint menu system.
YES
CURSOR
EXIT
CHANGE/NO
Light up
Caution
Functions of the keys
After each menu item is printed, the printer will also print the function of
each of the buttons at that time. They vary slightly depending on the menu
selected but generally fit the following guidelines:
PAUSE key (YES):
It is pushed to either select the current menu option or to save the new
setting after which it advances to the next menu.
STOP key (CHANGE/NO):
Whilst changing a menu value (such as head temperature), pressing this
key displays the next menu value available but does not save the setting.
In the “main menu“, pressing this key moves to the next menu available.
FEED key (CURSOR):
With some menu options such as head temperature, there is more than
one “digit” than can be changed.
This key moves the cursor to the next digit.
MODE/REPEAT key (EXIT):
Exits the current menu or the VuePrint menu system.
Mode Settings
When you are changing a menu value, pressing the "PAUSE" key (YES)
causes the printer to save the currently selected parameter. The
CONDITION LED flashes briefly. Do not turn off the power to the
printer at this time as this may cause a malfunction.
If the power is accidentally turned off, first reset the printer to factory
defaults.
