Printer Operation
32
Menu Setting Table
Page Setup Menu - allows you to change settings related to the media or print quality.
System Setup Menu - allows you to change settings for the printer hardware and basic control systems.
After Print Menu - changes how the printer reacts after the label has been printed.
Interfaces - changes interface parameters such as baud rate.
Top Menu Sub Menu Default Menu
Remarks
*Page Setup Print Speed 4 IPS 2 to 4 IPS
Printing speed setting
Print Darkness 10 00 to 30
Print darkness setting (printhead temperature)
Continuous Media
4.00 IN 0.25 to 32.00 IN
Length
101.6mm 6.35 to 812.8mm
Vertical Position 0.00 IN -1.00 to 1.00 IN
0.0mm -25.4 to 25.4mm
Horizontal Shift 0.00 IN -1.00 to 1.00 IN
Horizontal printing location adjustment
0.0mm 25.4 to 25.4mm
Media Sensor
See Through
See Through
Label sensor selection
Reflect
None
Small Media OFF ON
Setting for small labels
Adjustment OFF
Small Media 1.00 IN 0.25 to 1.00 IN
Setting length of small label media
Length
25.4mm 6.35 to 25.4mm
*System Setup Sensor Level 1.5V 0.0V to 3.3V
Setting the threshold of the sensor
Buzzer Select ON ON
Setting buzzer sounding conditions
OFF
Metric/Inch Inch Inch
Setting the units used
mm
Max Media Length 10.00 IN 1.00 to 50.00 IN
Setting the maximum label length
254.0mm
25.4 to 1270.0mm
Settings Lock Off On/Off
Keyboard Lock Off On/Off
Prevents the control panel from affecting the
printer's conrfiguration. (User "lock-out")
Control Code STD STD/ALT
Uses the command instead of STX in DMX
(DMX Mode Only)
mode. Sometimes called "AS400 emulation"
Emulation Select DM4
Datamax compatibility selection
DMI DMI DataMax IClass
DM4 DM4 DataMax 430 like
DPP DPP DataMax Prodigy Plus
Menu Setting
Print start position adjustment; the
lower line is in metric mode.
Mode Settings
Setting default length of continuous
media, if selected.
When on, prevents software commands from
changing the values set by the VuePrint menu
