6.2 DIP Switch Functions
DIP Switches
Switch No. Function ON OFF
Factory
Setting
1
Setting and selecting
DIP switch setting is DIP switch setting is ON
condition for communication
enabled. disabled.
2 Communication mode Xon/Xoff DTR/DSR OFF
3 Bit length 7-bit 8-bit OFF
4 Parity check With parity No parity OFF
5 Selecting parity Even parity Odd parity OFF
6 ON
7 ON
8 INIT Reset Disabled OFF
Table 1 Selecting baud rate
Switch No.
67
2,400 OFF OFF
4,800 ON OFF
9,600 OFF ON
19,200 ON ON
Selecting baud rate
Baud Rate
(bps)
(See Table 1)
