Specifications
Hardware and Software Guide A–3
Expansion Port Input/Output Signals
The expansion port signal information in this section may be
helpful if you plan to use an optional expansion product that
connects to the expansion port on your notebook.
This port is illustrated in the “Left-Side Components” section of
Chapter 1, “Hardware.”
Optional expansion products that connect to the notebook
through the expansion port may include a docking device or
a media cable.
The following table identifies the input and output signals
supported by the expansion port on your notebook.
Feature Support
USB 2.0 Yes
10/100 Ethernet Yes
Gigabit Ethernet No
IEEE 1394 (4-pin port) Yes
Consumer IR (for optional remote control only) Yes
Power inputs 65 W
Composite TV Yes
S-Video TV Yes
Component TV No
S/PDIF audio* Yes
DVI No
Headphone/speaker audio-out Yes
Microphone audio-in Yes
*Requires the use of an optional expansion product.
