wire cable attached. You attach one end of the cable to your desk (or other stationary object) and the
other end of the cable to the security slot on the computer. Secure the security lock with the key.
Figure 2-32 Installing a Security Lock
Attaching the Computer to a Mounting Fixture
You can remove the computer from the stand and install it on a wall, monitor arm, or other mounting
fixture. There is a VESA adapter plate attached to the underside of the computer stand that is used
for mounting the computer.
Table 2-2 Mounting Specifications
Computer Dimensions (without stand)
Height
Width
Depth
405.2 mm
584.5 mm
86 mm
15.953 inches
23.012 inches
3.78 inches
Computer Weight (without stand, with VESA adapter plate)
Integrated Graphics
Discrete Graphics
8.75 kg
9.05 kg
19.29 lbs
19.95 lbs
VESA standard adapter plate hole patterns (height x width) 100 mm x 100 mm
100 mm x 200 mm
3.937 in x 3.937 in
3.937 in x 7.874 in
For instructions on mounting the computer, refer to the Wall-Mounting your HP TouchSmart User
Guide.
Synchronizing the Optional Wireless Keyboard or Mouse
The optional wireless keyboard and mouse are easy to set up. Just remove the battery tabs on both
the keyboard and the mouse. Also, make sure the Power switch on the bottom of the mouse is in the
ENWW Attaching the Computer to a Mounting Fixture 29
