Chapter 6
Special Procedures
Fibre Channel Arbitrated Loop Hub Monitor
128
Fibre Channel Arbitrated Loop Hub Monitor
History
• IPR 9902: Initial release
Supported Products
• Fibre Channel Arbitrated Loop Hub Model A3724A
• Fibre Channel Arbitrated Loop Hub Model A4839A
Special Requirements
The FC-AL Hub monitor requires:
Device Firmware revisions:
• Device Agent Firmware revision 2.14 or greater
• Hub Controller Firmware revision 3.06 or greater
Firmware and installation instructions are available at http://www.software.hp.com
C++ runtime support patches:
• 10.20 PHSS_16585 (supersedes PHSS_14262)
• 11.00 PHSS_16587 (supersedes PHSS_14577)
Before using the hub monitor, edit the monitor configuration file,
/var/stm/config/tools/monitor/dm_fc_hub.cfg, to indicate what hubs will be monitored. See
“Configuring the FC-AL Monitor Configuration File” on page 129, for more information.
Resource Path
Event monitoring: /connectivity/events/hubs/FC_hub
Status monitoring: /connectivity/status/hubs/FC_hub
Executable File
/usr/sbin/stm/uut/bin/tools/monitor/dm_fc_hub
Monitor Behavior
• The monitor uses polling only with a default interval of 60 minutes.
• At initial startup the monitor does not retrieve any log information from the hub.
PSM State Control
The monitor does not support automatic state control. The set_fixed utility must be used to return a
hardware resource to the UP state following a failure. See “Configuring the FC-AL Monitor Configuration
File” on page 129, for more information.
