APPENDIX
SPECIFICATIONS
IBM 9512-AW*/ AB* TFT Color LCD Monitor
Driving system TFT Color LCD
LCD Panel Size 381mm(15.0")
Pixel pitch 0.297mm(H) x 0.297mm(V)
Viewable angle
120° (H) 100° (V)
Response time 30 ms
Video R, G, B Analog Interface
Input Separate Sync. H/V TTL
H-Frequency 30kHz – 60kHz
V-Frequency 55Hz-75Hz
Display Colors 16.7 million Colors
Dot Clock 80MHz
Max. Resolution 1024 x 768
Plug & Play VESA EDDC
EPA ENERGY STAR®
ON Mode <
30W
Active OFF <3W
OFF Mode <1W at 100Vac
<2W at 220Vac
Input Connector D-Sub 15pin
Input Video Signal Analog:0.7Vp-p 75 OHM,
Maximum Screen Size Horizontal: 304.1mm (12.0”)
Vertical: 228.1mm (9.0”)
Power Source 100~240VAC,50~60Hz
Environmental
Considerations
Operating Temp: 10°C to 35°C
5°F to 95°F
Ship/Storage Temp: -20° to 60°C
-4°F to 140°F
Operating Humidity: 10% to 80%
non-condensing
Ship/Storage Humidity:
5% to 95% non-condensing
Weight (N. W.)
unpackaged:
packaged:
4.8kgs
6.2Kgs
Regulatory
Compliance
UL, CSA, FCC, TÜV, CE,
TCO’99 for Pearl White models
TCO’95 for Stealth Black models
13
