FACTORY PRESET TIMING TABLE
DISPLAY MODES
The display mode the monitor uses is controlled by the computer. Therefore,
you should refer to your computer documentation for details in how to change
display modes.
The image size, position and shape may change when the display mode
changes. This is normal and the image can be readjusted using the monitor
controls.
Unlike CRT monitors, which require a high refresh rate to minimize flicker,
TFT technology is inherently flicker-free. If possible, configure your computer
for 1024 X 768 addressability at 60Hz vertical refresh rate.
For the display modes listed below, the screen image has been optimized
during manufacture.
Factory Set Display Modes
ADDRESSABILITY
REFRESH RATE
HORIZONTAL
FREQUENCY
640 × 350 70Hz 31.5kHz
640 × 480 60Hz 31.5kHz
640 × 480 72Hz 37.9kHz
640 × 480 75Hz 37.5kHz
640 × 480 67Hz 35.0kHz
720 × 400 70Hz 31.5kHz
800 × 600 75Hz 46.9kHz
800 × 600 72Hz 48.1kHz
800 × 600 60Hz 37.9kHz
800 × 600 56Hz 35.2kHz
832 × 624 75Hz 49.7kHz
1024 × 768+ 60Hz 48.4kHz
1024 × 768 70Hz 56.5kHz
1024 × 768 75Hz 60.0kHz
+ Recommended
15
