Appendix
Client for Microsoft Setup for Windows 98
If you are installing the Phoneline + 10/100 USB Network Adapter in a
Windows 98 PC that you plan on logging into a NT domain server, follow the
directions below.
1. Start up Windows. Click on Start, Settings, then Control Panel. Double-
click on Network. The Network window appears. Click on the
Configuration tab.
2. In the Primary Logon Box, you have two choices. Choose one Client for
Microsoft Networks, which instructs your PC to log into an NT 4.0 or
Windows 2000 server where you already have a username and password
set up.
3. Under the the following network components are installed box, highlight
Client for Microsoft Networks and click on the Properties button.
4. The Client for Networks Properties window will appear. Under the Logon
Validation box, make sure that Log on to Windows NT domain is checked.
Enter the name of your domain into the Windows NT Domain box
5. Optional: Click on the Access Control tab. Make sure that Share-level
access control is selected; do not choose User-level access control. If
Access Control is grayed out and cannot be selected, refer to Problem 5 in
the Troubleshooting section on page 46.
6. When you’re done, click OK. When asked if you want to restart your PC,
choose to do so.
The Microsoft Client portion of the Windows setup is complete.
