5.0 SPECIFICATIONS
Typical for 25°C unless otherwise specified.
Power consumption
+5V 1.0A typical, 1.25A max
Analog input section
Input amplifier type INA110
Number of channels 16 differential
Input range ±10V
Gains X1, X10, X100, X110, X200, X210, X300, X310,
X500, X510, X600, X610, X700, X710, X800,
X810
Gain error
Gain = 1 0.02% max, 0.002% typical
Gain = 10 0.05% max, 0.005% typical
Gain = 100 0.1% max, 0.01% typical
Gain = 200 0.2% max, 0.02% typical
Gain = 500 0.5% max, 0.05% typical
Nonlinearity
Gain = 1 0.005% max, 0.0005% typical
Gain = 10 0.01% max, 0.001% typical
Gain = 100 0.01% max, 0.002% typical
Gain = 200 0.01% max, 0.003% typical
Gain = 500 0.02% max, 0.005% typical
Temperature coefficient
Gain = 1 ±20 ppm / Deg C
Gain = 10 ±20 ppm / Deg C
Gain = 100 ±40 ppm / Deg C
Gain = 200 ±60 ppm / Deg C
Gain = 500 ±100 ppm / Deg C
Offset ±15mV / Deg C
Calibration Offset manually adjustable to 0
Common Mode Range ±10V
CMRR @ 60Hz 90 dB
Input leakage current 200 pA
Absolute maximum input voltage ±35V
14
